Soft Tonneau Cover | Ford Courier Dual Cab | 1999 - 2006

Important Information if you have previously had a Tonneau Cover Fitted



Our Tonneau covers come with Bunji loops installed onto the cover so that you only need to install the buttons onto the ute tub. In most cases your existing installed buttons will line up to the position of the bunji loops on the cover. So its important to check the buttons and button information before ordering. This Tonneau Cover has 20 attached bunjis, there are 6 at the back and 7 on each side positioned like the photo depitcs, the Bunji size are size 170mm, which means 85mm drop on each side.. If your existing buttons will not match up to this then you need to order a Blank Replacement Tonneau which will not have the bunji loops installed on the cover. But the Blank Tonneau Covers are made to order whereas the standard tonneaus are normally pre-made and ready to ship, so because they need to individually made to order the factory charge an extra manufacturing cost for the special order, so its best to get the standard tonneau cover if it fits with your existing installed buttons



Ford Courier PE - PG - PH Dual Cab Bunji Style Tonneau | 1999 to 2006

Ford Courier PE - PG - PH Dual Cab Bunji Style Tonneau | 1999 to 2006

Additional Information

Part # TONNEAU-UCDTFD470B
Brand Coverworld Range
* Soft Tonneau Cover has a fully water proof lining on the top & the bottom of the Cover
* This Soft Tonneau will NOT Stretch or Shrink, also made with Rot Proof Bonded Thread
* Superier UV Resistance with the Tonneau Cover Material
* Australian made with super fast manufacturing turnaround time and Expedited delivery times
* 3 Year Manufacturers Warranty - Warranty card must be completed
Material Rip Stop Material
Shipping Made to Order usually dispatched within 5 days

* Required Fields

$189.00
Ford Courier PE - PG - PH Dual Cab Bunji Style Tonneau | 1999 to 2006

Mouse over to zoom image

Details

Ford Courier Dual Cab PE - PG - PH 1999 to 2006

If you have existing installed buttons you only need to order the blank tonneau if your current installation does not match below and the instructions
Soft Tonneau Cover | Supplied with Fitting Kit
From Date : 1999 | End Date : 2006
Product Detail : Bunji Loop Style Tonneau Cover
Requires installation of Buttons onto Ute Tub
Not for use with Headboard or Cabin Guard or Tub Liner



Soft Tonneau Cover for Ford Courier PE - PG - PH _ 1999 to 2006



Supplied with Full Kit including support bar, this Soft Tonneau Cover is the bunji loop style. If you have previously had a tonneau cover fitted you may need a blank tonneau without the bunji lops fixed onto the cover, you can install the bunji loops onto your cover to match the locations of your vehicles buttons. Check the image details and bunji and button information before ordering this cover if you have previously had buttons installed



This Tonneau Cover has a marine carpet underside that provides protection to stop the paintwork of your Ute Styleside Ute from being scuffed from Tonneau Cover usage.



The Soft Tonneau is manufactured in Australia using quality components such and is provided with a 3 Year manufacturers warranty



The standard Manufacturing lead time is 1-2 days for all Soft Tonneaus and Express couriers are used for quick Australia wide delivery



We also provide Tonneau Cover Cleaner and Aerospace Protectant to help prolong the lifespan even further of this cover which is an optional product



A warranty card needs to be completed within 30 days of cover order placement and the instructions are also sent by email with your order confirmation after purchase

I have already had a Soft Tonneau Cover fitted previously so can I use this Soft Tonneau Cover on my vehicle?

Yes : If you have already had a Bunji style Tonneau Cover fitted then you will already have buttons on the side of the vehicle, so its important to check the buttons and bunji quantity and position before ordering.  In some infrequent cases the Tonneau Cover we will supply is called a "Blank Tonneau" this means that the bunji loops will not be fixed to the Tonneau Cover when it is delivered you will need to install the bunji loops to line up with your existing buttons. A centre punch is required to install the Bunji loops onto blank Tonneau Covers.  The manufacturing time is up to 5 days for a "Blank Tonneau"



If you have previoulsy had a Clip On Tonneau cover that you are replacing it will be necessary to remove your currently installed side rails and replace with the supplied rails and components with this kit

Blank Tonneau Covers are not supplied with a Tonno Lock.  They are also a special order item and cannot be returned due to change of mind or order error.

Are there any reccomended procedures I should carry out to maximise the lifespan of my Soft Tonneau Cover ?

Yes:  The following procedures should be carried out for general Soft Tonneau Cover Maintenance :

1)Apply Bees Wax or Dri-Lube to Stitching at least twice per year, this will maintain the tonneau covers waterproofing ability and prevent stitching from degrading, a natural result of weather exposure.

2) For best cleaning results we reccomend that you use our Tonneau and Convertible Top Cleaning product, do not use any harsh chemicals or cleaning agents on the Tonneau Cover.

3)For extended lifespan 303 Aerospace Protectant offers advanced UV treatment and has been shown the extend life spans of PVC's and Vinyls exposed to the weather and UV

Do I need to use Support Bars?

Yes : The support bars reduce pressure on the Soft Tonneau under driving conditions, as they prevent flapping which can damage the UV lamination on the Tonneau Cover material.  Most Tonneau Cover are supplied with support bars, check the inclusions for this Tonneau, if support bars are not included and you dont currently have any then we reccomend purchasing them, your warranty could be voided if the cover it not properly used and installed.

Will the Tonneau Cover scratch the sides of my styleside Ute Body?

No : The Tonneau Cover has a soft felt lining runnning along the inside on your Tray edge and it will not scratch your vehicle

I have Sports Bars and / or Ladder Racks on my vehicle can you adjust the Soft Tonneau Cover to fit around them?

No : We do not do any custom modifications to our standard Tonneau Cover patterns, if you require special cut outs then you would need to take the Soft Tonneau Cover to a local Auto Trimmer and ask them to make these modifications for you.  Check this is possible before you place the order.

Do you Offer a Fitting Service?

No, all Tonneau Covers are supplied with esay to follow instructions which you can download before purchasing, typically an installation will take approximately one hour.

Do I need to buy any additional special tools or equipment?

All Fitting instructions detail any extra tools that are required for installation, check the instructions before purchasing, in most cases the standard fitting tools required are:

  • Rivet Gun
  • Drill
  • Marking Pen / Pencil
  • You will need to buy a small padlock to go through the Tonno Lock

I would prefer to use the Clip on No Body Drilling Soft Tonneau but sometimes the items in my ute extend a bit higher than the tray sides so will the Clip on Cover still fit?

Yes, Oversize loads are not a hassle with our stretch cord clip on system that hides out of sight under the cover until needed

I would prefer to use the Clip on No Body Drilling Soft Tonneau Cover but cant find one for my vehicle?

Clip On Soft Tonneau Covers are being introduced for most popular new vehicles as they are released.

What happens if I order the wrong Soft Tonneau Cover?

You should be able to find the exact Soft Tonneau Cover for your vehicle listed on our website, if you cannot see your model listed then please contact us before placing an order, as if your Tonneau Cover needs to be returned because of an ordeirng error then you will need to pay for the return freight costs and deducted from your refund will be a 10% restocking fee and your original delivery cost will not be refunded.  Blank special order tonneau covers cannot be returned so please order a blank tonneau cover carefully.

Do you have a question that we have not answered ? Please detail your question below and we will come back to you soon.

Please describe your question so that we can assist you.
Please put this part number |TONNEAU-UCDTFD470B| in the Part Number box below.

Fitting Instructions for the Courier PE PG PH






You will need the following extra tools for cover installation



  • Pop Rivet Gun
  • Drill
  • 4mm Drill Bit
  • Measuring Tape
  • Anti-corrosive primer
  • 3mm Allen Key



Contents

    • 1 x Tonneau Cover
    • 2 x Bar Brackets
    • 1 x Tonneau Support Bar
    • 30 x Aluminium Rivets
    • 20 x Buttons
    • Universal Support Bar kit
    • 1 x Support Bar Coverall



Please read the fitting instructions before ordering this Soft Tonneau Cover.



Fitting Instructions

This cover has 20 installed bunjis that are part B150 which are 75mm length, 7 on each side, and 6 at the back


If you are ordering a Blank Tonneau cover because your buttons and bunjis do not match the standard cover design then the bunji loops will not be attached and you need to attach them. A blank tonneau cover is a special order item and cannot be returned due to order error so please order carefully and contact us prior to ordering if you are unsure if this is the correct item for your vehicle

Please view our Standard Coverworld Terms before ordering.

Open Coverworld Terms Here


There is a lot of information on our Terms page, please read them and feel free to ask any questions, we have friendly sales staff ready to take your call or send us an email

If you nee to return this made to order tonneau cover due to an order error a 20 restocking fee applies on made to order tonneau covers.

Any component found to be defective in materials or workmanship within the warranty period will be repaired free of charge when returned to manufacturing facility premises in Mitcham, Victoria.

Please note: This warranty does not include transport and insurance charges.The purchaser is required under this warranty, to return this registration form within 28 days from purchase date.

Please complete your Warranty Registration <a href="http://www.coverworld.com.au/warranty-registration.html">Tonneau Cover Warranty Registration Form</a>

A link to the warranty registration is sent automatically after you have made a purchase.

In the event of a warranty claim your Ute cover must be accompanied by proof of purchase receipt. Please ensure you retain your receipt with your warranty card.

Customers will need to pay return postage to Mictham, Victoria.



This warranty is void if the product has been damaged by an accident, abuse, negligence, mishandling or by violent atmospheric conditions.

The warranty is void is modifications to the original cover design are made.



Stormcovers Australia Pty Ltd takes no legal responsibility for injuries or deaths associated with the cover.

Please be aware Tonneau covers are NOT a load restraint.

Caring for your Ute cover: We recommend a mild detergent only and rinse thoroughly. To prolong your Ute Covers life we recommend using 303 Aerospace Protectant
